Caching in Python Using the LRU Cache Strategy

Implementing a Cache Using a Python Dictionary

You can implement a caching solution in Python using a dictionary.

Staying with the newsreader example, instead of going directly to the server every time you need to download an article, you can check whether you have the content in your cache and go back to the server only if you don’t. You can use the article’s URL as the key and its content as the value.

Here’s an example of how this caching technique might look:

 1import requests
 2
 3cache = dict()
 4
 5def get_article_from_server(url):
 6    print("Fetching article from server...")
 7    response = requests.get(url)
 8    return response.text
 9
10def get_article(url):
11    print("Getting article...")
12    if url not in cache:
13        cache[url] = get_article_from_server(url)
14
15    return cache[url]
16
17get_article("https://realpython.com/sorting-algorithms-python/")
18get_article("https://realpython.com/sorting-algorithms-python/")

Save this code to a caching.py file, install the requests library, then run the script:

$ pip install requests
$ python caching.py
Getting article...
Fetching article from server...
Getting article...

Notice how you get the string "Fetching article from server..." printed a single time despite calling get_article() twice, in lines 17 and 18. This happens because, after accessing the article for the first time, you put its URL and content in the cache dictionary. The second time, the code doesn’t need to fetch the item from the server again.

Caching Strategies

There’s one big problem with this cache implementation: the content of the dictionary will grow indefinitely! As the user downloads more articles, the application will keep storing them in memory, eventually causing the application to crash.

To work around this issue, you need a strategy to decide which articles should stay in memory and which should be removed. These caching strategies are algorithms that focus on managing the cached information and choosing which items to discard to make room for new ones.

There are several different strategies that you can use to evict items from the cache and keep it from growing past from its maximum size. Here are five of the most popular ones, with an explanation of when each is most useful:

In the sections below, you’ll take a closer look at the LRU strategy and how to implement it using the @lru_cache decorator from Python’s functools module.

Diving Into the Least Recently Used (LRU) Cache Strategy

A cache implemented using the LRU strategy organizes its items in order of use. Every time you access an entry, the LRU algorithm will move it to the top of the cache. This way, the algorithm can quickly identify the entry that’s gone unused the longest by looking at the bottom of the list.

The following figure shows a hypothetical cache representation after your user requests an article from the network:

Notice how the cache stores the article in the most recent slot before serving it to the user. The following figure shows what happens when the user requests a second article:

The second article takes the most recent slot, pushing the first article down the list.

The LRU strategy assumes that the more recently an object has been used, the more likely it will be needed in the future, so it tries to keep that object in the cache for the longest time.

Peeking Behind the Scenes of the LRU Cache

One way to implement an LRU cache in Python is to use a combination of a doubly linked list and a hash map. The head element of the doubly linked list would point to the most recently used entry, and the tail would point to the least recently used entry.

The figure below shows the potential structure of the LRU cache implementation behind the scenes:

Using the hash map, you can ensure access to every item in the cache by mapping each entry to the specific location in the doubly linked list.

This strategy is very fast. Accessing the least recently used item and updating the cache are operations with a runtime of O(1).

Since version 3.2, Python has included the @lru_cache decorator for implementing the LRU strategy. You can use this decorator to wrap functions and cache their results up to a maximum number of entries.

Playing With Stairs

Imagine you want to determine all the different ways you can reach a specific stair in a staircase by hopping one, two, or three stairs at a time. How many paths are there to the fourth stair? Here are all the different combinations:

You could frame a solution to this problem by stating that, to reach your current stair, you can jump from one stair, two stairs, or three stairs below. Adding up the number of jump combinations you can use to get to each of those points should give you the total number of possible ways to reach your current position.

For example, the number of combinations for reaching the fourth stair will equal the total number of different ways you can reach the third, second, and first stair:

As shown in the picture, there are seven different ways to reach the fourth stair. Notice how the solution for a given stair builds upon the answers to smaller subproblems. In this case, to determine the different paths to the fourth stair, you can add up the four ways of reaching the third stair, the two ways of reaching the second stair, and the one way of reaching the first stair.

This approach is called recursion. If you want to learn more, then check out Recursion in Python: An Introduction for an introduction to the topic.

Here’s a function that implements this recursion:

 1def steps_to(stair):
 2    if stair == 1:
 3        # You can reach the first stair with only a single step
 4        # from the floor.
 5        return 1
 6    elif stair == 2:
 7        # You can reach the second stair by jumping from the
 8        # floor with a single two-stair hop or by jumping a single
 9        # stair a couple of times.
10        return 2
11    elif stair == 3:
12        # You can reach the third stair using four possible
13        # combinations:
14        # 1. Jumping all the way from the floor
15        # 2. Jumping two stairs, then one
16        # 3. Jumping one stair, then two
17        # 4. Jumping one stair three times
18        return 4
19    else:
20        # You can reach your current stair from three different places:
21        # 1. From three stairs down
22        # 2. From two stairs down
23        # 2. From one stair down
24        #
25        # If you add up the number of ways of getting to those
26        # those three positions, then you should have your solution.
27        return (
28            steps_to(stair - 3)
29            + steps_to(stair - 2)
30            + steps_to(stair - 1)
31        )
32
33print(steps_to(4))

Save this code into a file named stairs.py and run it with the following command:

$ python stairs.py
7

Great! The code works for 4 stairs, but how about counting how many steps to reach a higher place in the staircase? Change the stair number in line 33 to 30 and rerun the script:

$ python stairs.py
53798080

Wow, more than 53 million combinations! That’s a lot of hops!

Timing Your Code

When finding the solution for the thirtieth stair, the script took quite a bit of time to finish. To get a baseline, you can measure how long it takes for the code to run.

To accomplish this, you can use Python’s timeit module. Add the following lines after line 33:

35setup_code = "from __main__ import steps_to"
36stmt = "steps_to(30)"
37times = repeat(setup=setup_code, stmt=stmt, repeat=3, number=10)
38print(f"Minimum execution time: {min(times)}")

You also need to import the timeit module at the top of the code:

 1from timeit import repeat

Here’s a line-by-line explanation of these additions:

• Line 35 imports the name of steps_to() so that timeit.repeat() knows how to call it.
• Line 36 prepares the call to the function with the stair number you want to reach, which in this case is 30. This is the statement that will be executed and timed.
• Line 37 calls timeit.repeat() with the setup code and the statement. This will call the function 10 times, returning the number of seconds each execution took.
• Line 38 identifies and prints the shortest time returned.

Now run the script again:

$ python stairs.py
53798080
Minimum execution time: 40.014977024000004

The number of seconds you’ll see depends on your specific hardware. On my system, the script took forty seconds, which is quite slow for just thirty stairs!

A solution that takes this long is a problem, but you can improve it using memoization.

Using Memoization to Improve the Solution

This recursive implementation solves the problem by breaking it into smaller steps that build upon each other. The following figure shows a tree in which every node represents a specific call to steps_to():

Notice how you need to call steps_to() with the same argument multiple times. For example, steps_to(5) is computed two times, steps_to(4) is computed four times, steps_to(3) seven times, and steps_to(2) six times. Calling the same function more than once adds computation cycles that aren’t necessary—the result will always be the same.

To fix this problem, you can use a technique called memoization. This approach ensures that a function doesn’t run for the same inputs more than once by storing its result in memory and then referencing it later when necessary. This scenario sounds like the perfect opportunity to use Python’s @lru_cache decorator!

With just two changes, you can considerably improve the algorithm’s runtime:

1. Import the @lru_cache decorator from the functools module.
2. Use @lru_cache to decorate steps_to().

Here’s what the top of the script will look like with the two updates:

 1from functools import lru_cache
 2from timeit import repeat
 3
 4@lru_cache
 5def steps_to(stair):
 6    if stair == 1:

Running the updated script produces the following result:

$ python stairs.py
53798080
Minimum execution time: 7.999999999987184e-07

Caching the result of the function takes the runtime from 40 seconds down to 0.0008 milliseconds! That’s a fantastic improvement!

Remember, behind the scenes, the @lru_cache decorator stores the result of steps_to() for each different input. Every time the code calls the function with the same parameters, instead of computing an answer all over again, it returns the correct result directly from memory. This explains the massive improvement in performance when using @lru_cache.

Unpacking the Functionality of @lru_cache

With the @lru_cache decorator in place, you store every call and answer in memory to access later if requested again. But how many calls can you save before running out of memory?

Python’s @lru_cache decorator offers a maxsize attribute that defines the maximum number of entries before the cache starts evicting old items. By default, maxsize is set to 128. If you set maxsize to None, then the cache will grow indefinitely, and no entries will be ever evicted. This could become a problem if you’re storing a large number of different calls in memory.

Here’s an example of @lru_cache using the maxsize attribute:

 1from functools import lru_cache
 2from timeit import repeat
 3
 4@lru_cache(maxsize=16)
 5def steps_to(stair):
 6    if stair == 1:

In this case, you’re limiting the cache to a maximum of 16 entries. When a new call comes in, the decorator’s implementation will evict the least recently used of the existing 16 entries to make a place for the new item.

To see what happens with this new addition to the code, you can use cache_info(), provided by the @lru_cache decorator, to inspect the number of hits and misses and the current size of the cache. For clarity, remove the code that times the runtime of the function. Here’s how the final script looks after all the modifications:

 1from functools import lru_cache
 2from timeit import repeat
 3
 4@lru_cache(maxsize=16)
 5def steps_to(stair):
 6    if stair == 1:
 7        # You can reach the first stair with only a single step
 8        # from the floor.
 9        return 1
10    elif stair == 2:
11        # You can reach the second stair by jumping from the
12        # floor with a single two-stair hop or by jumping a single
13        # stair a couple of times.
14        return 2
15    elif stair == 3:
16        # You can reach the third stair using four possible
17        # combinations:
18        # 1. Jumping all the way from the floor
19        # 2. Jumping two stairs, then one
20        # 3. Jumping one stair, then two
21        # 4. Jumping one stair three times
22        return 4
23    else:
24        # You can reach your current stair from three different places:
25        # 1. From three stairs down
26        # 2. From two stairs down
27        # 2. From one stair down
28        #
29        # If you add up the number of ways of getting to those
30        # those three positions, then you should have your solution.
31        return (
32            steps_to(stair - 3)
33            + steps_to(stair - 2)
34            + steps_to(stair - 1)
35        )
36
37print(steps_to(30))
38
39print(steps_to.cache_info())

If you call the script again, then you’ll see the following result:

$ python stairs.py
53798080
CacheInfo(hits=52, misses=30, maxsize=16, currsize=16)

You can use the information returned by cache_info() to understand how the cache is performing and fine-tune it to find the appropriate balance between speed and storage.

Here’s a breakdown of the properties provided by cache_info():

• hits=52 is the number of calls that @lru_cache returned directly from memory because they existed in the cache.

• misses=30 is the number of calls that didn’t come from memory and were computed. Since you’re trying to find the number of steps to reach the thirtieth stair, it makes sense that each of these calls missed the cache the first time they were made.

• maxsize=16 is the size of the cache as you defined it with the maxsize attribute of the decorator.

• currsize=16 is the current size of the cache. In this case, it shows that your cache is full.

If you need to remove all the entries from the cache, then you can use cache_clear() provided by @lru_cache.

Evicting Cache Entries Based on Both Time and Space

The @lru_cache decorator evicts existing entries only when there’s no more space to store new listings. With sufficient space, entries in the cache will live forever and never get refreshed.

This presents a problem for your monitoring script because you’ll never fetch updates published for previously cached articles. To get around this problem, you can update the cache implementation so it expires after a specific time.

You can implement this idea into a new decorator that extends @lru_cache. If the caller tries to access an item that’s past its lifetime, then the cache won’t return its content, forcing the caller to fetch the article from the network.

Here’s a possible implementation of this new decorator:

 1from functools import lru_cache, wraps
 2from datetime import datetime, timedelta
 3
 4def timed_lru_cache(seconds: int, maxsize: int = 128):
 5    def wrapper_cache(func):
 6        func = lru_cache(maxsize=maxsize)(func)
 7        func.lifetime = timedelta(seconds=seconds)
 8        func.expiration = datetime.utcnow() + func.lifetime
 9
10        @wraps(func)
11        def wrapped_func(*args, **kwargs):
12            if datetime.utcnow() >= func.expiration:
13                func.cache_clear()
14                func.expiration = datetime.utcnow() + func.lifetime
15
16            return func(*args, **kwargs)
17
18        return wrapped_func
19
20    return wrapper_cache

Here’s a breakdown of this implementation:

• Line 4: The @timed_lru_cache decorator will support the lifetime of the entries in the cache (in seconds) and the maximum size of the cache.
• Line 6: The code wraps the decorated function with the lru_cache decorator. This allows you to use the cache functionality already provided by lru_cache.
• Lines 7 and 8: These two lines instrument the decorated function with two attributes representing the lifetime of the cache and the actual date when it will expire.
• Lines 12 to 14: Before accessing an entry in the cache, the decorator checks whether the current date is past the expiration date. If that’s the case, then it clears the cache and recomputes the lifetime and expiration date.

Notice how, when an entry is expired, this decorator clears the entire cache associated with the function. The lifetime applies to the cache as a whole, not to individual articles. A more sophisticated implementation of this strategy would evict entries based on their individual lifetimes.

Caching Articles With the New Decorator

You can now use your new @timed_lru_cache decorator with the monitor script to prevent fetching the content of an article every time you access it.

Putting the code together in a single script for simplicity, you end up with the following:

 1import feedparser
 2import requests
 3import ssl
 4import time
 5
 6from functools import lru_cache, wraps
 7from datetime import datetime, timedelta
 8
 9if hasattr(ssl, "_create_unverified_context"):
10    ssl._create_default_https_context = ssl._create_unverified_context
11
12def timed_lru_cache(seconds: int, maxsize: int = 128):
13    def wrapper_cache(func):
14        func = lru_cache(maxsize=maxsize)(func)
15        func.lifetime = timedelta(seconds=seconds)
16        func.expiration = datetime.utcnow() + func.lifetime
17
18        @wraps(func)
19        def wrapped_func(*args, **kwargs):
20            if datetime.utcnow() >= func.expiration:
21                func.cache_clear()
22                func.expiration = datetime.utcnow() + func.lifetime
23
24            return func(*args, **kwargs)
25
26        return wrapped_func
27
28    return wrapper_cache
29
30@timed_lru_cache(10)
31def get_article_from_server(url):
32    print("Fetching article from server...")
33    response = requests.get(url)
34    return response.text
35
36def monitor(url):
37    maxlen = 45
38    while True:
39        print("\nChecking feed...")
40        feed = feedparser.parse(url)
41
42        for entry in feed.entries[:5]:
43            if "python" in entry.title.lower():
44                truncated_title = (
45                    entry.title[:maxlen] + "..."
46                    if len(entry.title) > maxlen
47                    else entry.title
48                )
49                print(
50                    "Match found:",
51                    truncated_title,
52                    len(get_article_from_server(entry.link)),
53                )
54
55        time.sleep(5)
56
57monitor("https://realpython.com/atom.xml")

Notice how line 30 decorates get_article_from_server() with the @timed_lru_cache and specifies a validity of 10 seconds. Any attempt to access the same article from the server within 10 seconds of having fetched it will return the contents from the cache and never hit the network.

Run the script and take a look at the results:

$ python monitor.py

Checking feed...
Fetching article from server...
Match found: The Real Python Podcast – Episode #28: Using ... 29521
Fetching article from server...
Match found: Python Community Interview With David Amos 54254
Fetching article from server...
Match found: Working With Linked Lists in Python 37100
Fetching article from server...
Match found: Python Practice Problems: Get Ready for Your ... 164887
Fetching article from server...
Match found: The Real Python Podcast – Episode #27: Prepar... 30783

Checking feed...
Match found: The Real Python Podcast – Episode #28: Using ... 29521
Match found: Python Community Interview With David Amos 54254
Match found: Working With Linked Lists in Python 37100
Match found: Python Practice Problems: Get Ready for Your ... 164887
Match found: The Real Python Podcast – Episode #27: Prepar... 30783

Checking feed...
Match found: The Real Python Podcast – Episode #28: Using ... 29521
Match found: Python Community Interview With David Amos 54254
Match found: Working With Linked Lists in Python 37100
Match found: Python Practice Problems: Get Ready for Your ... 164887
Match found: The Real Python Podcast – Episode #27: Prepar... 30783

Checking feed...
Fetching article from server...
Match found: The Real Python Podcast – Episode #28: Using ... 29521
Fetching article from server...
Match found: Python Community Interview With David Amos 54254
Fetching article from server...
Match found: Working With Linked Lists in Python 37099
Fetching article from server...
Match found: Python Practice Problems: Get Ready for Your ... 164888
Fetching article from server...
Match found: The Real Python Podcast – Episode #27: Prepar... 30783

Notice how the code prints the message "Fetching article from server..." the first time it accesses the matching articles. After that, depending on your network speed and computing power, the script will retrieve the articles from the cache either one or two times before hitting the server again.

The script tries to access the articles every 5 seconds, and the cache expires every 10 seconds. These times are probably too short for a real application, so you can get a significant improvement by adjusting these configurations.
